Panache Close Coupled Toilet Suite
Wels Water Rating

Panache Close Coupled Toilet Suite

Modern and contemporary, the perfect addition to any bathroom.

Enquire Download Spare Parts PDF
Features
  • Dual flush (4.5/3L)
  • Bottom left or right inlet
  • S-trap set out (with vario pan connector): 90mm-170mm
  • P-trap set out: 185mm
  • Box rim
Included Components
  • Panache toilet pan
  • Panache toilet cistern 4.5/3L
  • Panache quiet close toilet seat
  • Vario pan connector
  • Fill valve
  • Bottom inlet plug
  • Floor fixing bolts and anchors
Installation Instructions
  • Water supply pressure range
  • 20 psi (137 kPa) - 80 psi (551 kPa).
  • Can be installed as a P-trap using a straight connector (not supplied) or as an S-trap using the vario connector (supplied).
  • Bottom inlet is standard.
  • The installation of a remotely located inlet shut-off valve (not supplied) is required.
Technical Information
